iFIX8 G2

Small Cabinet. Big Attitude.

Installation Point source speakers iFIX

Where to buy

Description

Big sound in a small package—that's the promise of the CELTO iFIX8 G2, delivering a solid 300W RMS with exceptional efficiency. This coaxial installation loudspeaker is engineered for high-impact near-field reinforcement when paired with a subwoofer. Ideal for vibrant nightclubs, pubs, restaurants, multifunctional venues, auditoriums, and premium background music setups. Its 8" coaxial driver with HSP annular ring radiator HF delivers outstanding clarity and an impressive SPL-to-size ratio. Audiophile-grade crossover with Right-Phase design ensures seamless integration and precise imaging. Built from robust birch plywood and finished in black, white, natural wood, or custom colors to suit any interior. Multi-function yoke bracket included for quick, reliable wall or ceiling mounting. With 95 dB sensitivity and 126 dB peak SPL, it transforms compact spaces into sonic powerhouses. Proof that you don't need massive cabinets to achieve massive sound—the iFIX8 G2 simply gets the job done with style.

Key Features

Real 300W RMS with high-end sound quality
High Efficiency for incredible SPL to Size ratio
Coaxial transducer for unmatched spacial coherence
Next generation HSP Annular Ring Radiator HF
Audiophile grade crossover with Right-Phase topology
Birch plywood cabinet with smooth texture or varnish finish

Applications

Installation Sound Architecture

Technical specifications

Speaker type	FIX Install Full Range Coaxial Speaker
Power Handling (AES standard)	300 W RMS / 1200 W Peak
Nominal impedance	8Ω
Average sensitivity	95 dB / 1 W / 1 m
Maximum SPL (calculated)	120 dB RMS / 126 dB Peak
Frequency response (-6 dB no preset)	95~22000 Hz
Nominal directivity (-6 dB)	80° conical
Cabinet	Exterior grade Birch plywood Tongue & Groove construction
Cabinet finish	Textured Waterborne Black coating Acoustic PU foam behind Front grill
Floor monitor use	No
Flying hardware	Multi-function Yoke with dented ring (can be mounted with screws or Eyebolt, Included in carton)
Mounting hardware	Yes for Yoke, wall mount bracket and CCA-MA
LF	8" coaxial CELTO 8CXT250
Woofer Chassis	Die Cast Aluminium
Woofer Voice coil	2.5" / 65 mm
HF	CELTO ACDX 40 (single magnet coaxial mounting)
HF RMS power (AES standard)	60 W above 1.5 kHz
HF Exit	1" / 25 mm
HF Voice coil diameter	1.7" / 44 mm
HF Diaphragm	HSP Annular (High Strength Polymer)
Crossover	1.6 kHz 2-way passive network
Connectivity	PHOENIX MSTBV 2.5/4-GF-5.08 4 pin header 2.5 mm² wire / 5.08 mm pitch
Speaker size (HxWxD)	243 x 250 x 250 mm
Speaker Weight	7 kg
Shipping information	9 kg 350 x 320 x 370 mm
Accessories	CCA-MA (mounting adapter) WMBRKT20 (wall mount bracket) Rust-Free Aluninum grill

Product files

Name	Category	Type	Size
CELTO_IFIX8G2_BLK_A0_20250714_WEB_CAD CELTO_IFIX8G2_BLK_A0_20250714_WEB_CAD	CELTO_IFIX8G2_BLK_A0_20250714_WEB_CAD	PDF	66.5 KiB	Download
CELTO_IFIX8G2_BLK_A0_20250714_WEB_CAD CELTO_IFIX8G2_BLK_A0_20250714_WEB_CAD	CELTO_IFIX8G2_BLK_A0_20250714_WEB_CAD	DWG	901.5 KiB	Download
