Description
True full-range performance when space won't allow a subwoofer—the CELTO PM12 G3 unleashes a commanding 600W RMS (2400W peak) with deep, powerful low-frequency reproduction down to 40 Hz, courtesy of advanced Transmission Line technology.
This all-in-one passive loudspeaker delivers natural, incredibly holographic sound with outstanding clarity and dimensional imaging across larger areas.
Ideal for multi-purpose halls, dance schools, gyms, sports arenas, and any installation where authentic full-range coverage is essential without additional bass cabinets.
At its core, a premium 12" custom CELTO driver with 3" voice coil pairs seamlessly with the acclaimed ACD44 compression driver featuring HSP annular high-strength polymer diaphragm on a proprietary rotatable 80°x50° 6th-order Polynomial horn.
Exterior-grade birch plywood cabinet with tongue-and-groove assembly, textured waterborne black finish, 15 M8 rigging points, and dual-angle 35 mm pole socket ensure rugged, versatile deployment.
97 dB sensitivity and a thunderous 131 dB peak SPL provide effortless authority with smooth on- and off-axis response throughout 40–22,000 Hz.
Genuine Neutrik Speakon connectors and comprehensive bracket options simplify fixed or mobile installations.
The PM12 G3 proves that genuine full-range power, holographic precision, and real-world durability can coexist in one elegantly compact package.
Key Features
- Real 600W RMS power capacity (8 hours pink noise)
- Natural sound and incredible holographic reproduction
- Optimized for smooth frequency response in and out axis
- Transmission Line Technology for true full range
- Premium custom CELTO Drivers
- Proprietary 80°x50° rotatable 6th order Polynomial horn
- Birch plywood cabinet with tongue & groove assembly
- Multiple M8 flying points for versatile installation
Applications
Installation
Sound Architecture
Technical specifications
| Speaker type | Passive Full Range Speaker |
| Power Handling (AES standard) | 600 W RMS / 2400 W Peak |
| Nominal impedance | 8Ω |
| Average sensitivity | 97 dB / 1 W / 1 m |
| Maximum SPL (calculated) | 125 dB RMS / 131 dB Peak |
| Frequency response (-6 dB no preset) | 40~22000 Hz |
| Nominal directivity (-6 dB) | 80° (H) x 50° (V) |
| Cabinet |
Exterior grade Birch Plywood Tongue & Groove construction |
| Cabinet finish |
Textured Waterborne Black coating Acoustic PU foam behind Front grill |
| Floor monitor use | No |
| Flying hardware | 15 M8 points |
| Mounting hardware | Ø35 mm socket (0° and 10°) |
| LF | 12" CELTO 12PF601-8 |
| Woofer Chassis | Die Cast Aluminium |
| Woofer Voice coil | 3" / 75 mm |
| HF |
CELTO ACD44 |
| HF RMS power (AES standard) | 80 W above 1.5 kHz |
| HF Exit | 1" / 25 mm |
| HF Voice coil diameter | 1.7" / 44 mm |
| HF Diaphragm | HSP Annular (High Strength Polymer) |
| Crossover | 1.5 kHz 2-way passive network |
| Connectivity |
Genuine NEUTRIK 2pcs Speakon NL4MP |
| Speaker size (HxWxD) | 620 x 348 x 405 mm |
| Speaker Weight | 24 kg |
| Shipping information |
29 kg 720 x 450 x 515 mm |
| Accessories |
PM12-YOKE CPC-70 (pole bar with crank) KTV-BRKT1 (ceiling mounting braket) WMBRKT60 (wall mounting braket) |
