Description
World-premiere carbon dome technology takes center stage—the CELTO PM12V introduces a revolutionary HFD44/C high-frequency compression driver that slashes distortion to unprecedented lows, making high-volume listening feel effortlessly natural and fatigue-free.
This groundbreaking carbon dome with PI surround delivers voices and transients with uncanny realism, setting a new benchmark for clarity in professional audio.
Paired with a robust 12" custom CELTO LF driver (3" voice coil), the PM12V handles a genuine 500W RMS (2000W peak) with smooth, authoritative power across 45–22,000 Hz.
Proprietary rotatable 80°x50° elliptic horn ensures seamless coverage whether mounted horizontally or vertically—perfect for small rooms, electronic music venues, lounges, and intimate clubs.
Exterior-grade birch plywood cabinet with tongue-and-groove construction, textured waterborne black finish, 15 M8 rigging points, and dual-angle pole socket for fast, discreet installation.
97 dB sensitivity and up to 130 dB peak SPL provide commanding output without ever sounding strained.
Genuine Neutrik Speakon connectors and comprehensive bracket options make deployment effortless in any fixed setup.
Optimized passive crossover delivers consistent on- and off-axis response for even, immersive sound throughout the space.
The PM12V proves that carbon dome innovation isn’t just the future—it’s the new standard for natural, distortion-free sound today.
Key Features
- Real 500W RMS power capacity
- World Premiere Carbon dome technology
- Optimized for smooth frequency response in and out axis
- Premium custom made Drivers
- Proprietary 80°x50° rotatable elliptic horn
- Birch plywood cabinet with tongue & groove assembly
- Touring grade soft touch gloss-free black painting
Applications
Installation
Sound Architecture
Technical specifications
| Speaker type | Multi-purpose full range |
| Power Handling (AES standard) | 500 W RMS / 2000 W Peak |
| Nominal impedance | 8Ω |
| Average sensitivity | 97 dB / 1 W / 1 m |
| Maximum SPL (calculated) | 124 dB RMS / 130 dB Peak |
| Frequency response (-6 dB no preset) | 45~22000 Hz |
| Nominal directivity (-6 dB) | 80° (H) x 50° (V) |
| Cabinet |
Exterior grade Birch Plywood Tongue & Groove construction |
| Cabinet finish |
Textured Waterborne Black coating Acoustic PU foam behind Front grill |
| Floor monitor use | No |
| Flying hardware | 15 M8 points |
| Mounting hardware | Ø35 mm socket (0° and 10°) |
| LF | 12" CELTO 12PF600-8 |
| Woofer Chassis | Die Cast Aluminium |
| Woofer Voice coil | 3" / 75 mm |
| HF |
CELTO HFD44/C |
| HF RMS power (AES standard) | 60 W above 1.5 kHz |
| HF Exit | 1" / 25 mm |
| HF Voice coil diameter | 1.7" / 44 mm |
| HF Diaphragm | Carbon dome + PI Surround |
| Crossover | 1.6 kHz 2-way passive network |
| Connectivity |
Genuine NEUTRIK 2pcs Speakon NL4 MP |
| Speaker size (HxWxD) | 620 x 348 x 405 mm |
| Speaker Weight | 23 kg |
| Shipping information |
28 kg 720 x 450 x 515 mm |
| Accessories |
PM12-YOKE CPC-70 (pole bar with crank) KTV-BRKT1 (ceiling mounting braket) WMBRKT60 (wall mounting braket) |
