Description
World-premiere carbon dome technology redefines sensory immersion—the CELTO PM15V features the revolutionary HFD44/C compression driver that obliterates distortion, delivering music with an extreme sensory experience that feels vividly alive even at concert levels.
This groundbreaking carbon dome with PI surround renders vocals, transients, and harmonics with breathtaking naturalness and zero fatigue, setting an entirely new standard for high-fidelity reproduction.
Teamed with a powerful 15" custom CELTO LF driver (3.6" voice coil), the PM15V commands a true 500W RMS (2000W peak) with deep, authoritative bass extension down to 42 Hz.
Proprietary rotatable 80°x50° elliptic horn provides precise, uniform coverage in both horizontal and vertical orientations—ideal for medium-sized venues, clubs, electronic music spaces, and premium installations.
Exterior-grade birch plywood cabinet with tongue-and-groove assembly, textured waterborne black finish, 9 M8 rigging points, and dual-angle 35 mm pole socket ensure rugged reliability and effortless deployment.
98 dB sensitivity and a commanding 131 dB peak SPL deliver effortless room-filling power with pristine clarity across the full 42–22,000 Hz spectrum.
Genuine Neutrik Speakon connectors and dedicated yoke, wall, and pole bracket options make fixed or mobile setups fast and discreet.
Optimized passive crossover guarantees smooth on- and off-axis response for consistent, immersive sound everywhere in the room.
The PM15V proves that carbon dome innovation paired with serious low-end authority can turn ordinary music into an unforgettable, almost tangible experience.
Key Features
- Real 500W RMS power capacity
- World Premiere Carbon dome technology
- Optimized for smooth frequency response in and out axis
- Premium custom made Drivers
- Proprietary 80°x50° rotatable elliptic horn
- Birch plywood cabinet with tongue & groove assembly
- Touring grade soft touch gloss-free black painting
Applications
Installation
Sound Architecture
Technical specifications
| Speaker type | Multi-purpose full range |
| Power Handling (AES standard) | 500 W RMS / 2000 W Peak |
| Nominal impedance | 8Ω |
| Average sensitivity | 98 dB / 1 W / 1 m |
| Maximum SPL (calculated) | 125 dB RMS / 131 dB Peak |
| Frequency response (-6 dB no preset) | 42~22000 Hz |
| Nominal directivity (-6 dB) | 80° (H) x 50° (V) |
| Cabinet |
Exterior grade Birch Plywood Tongue & Groove construction |
| Cabinet finish |
Textured Waterborne Black coating Acoustic PU foam behind Front grill |
| Floor monitor use | No |
| Flying hardware | 9 M8 points |
| Mounting hardware | Ø35 mm socket (0° and 10°) |
| LF | 15" CELTO 15GN501-8 |
| Woofer Chassis | Die Cast Aluminium |
| Woofer Voice coil | 3.6" / 91 mm |
| HF |
CELTO HFD44/C |
| HF RMS power (AES standard) | 60 W above 1.5 kHz |
| HF Exit | 1" / 25 mm |
| HF Voice coil diameter | 1.7" / 44 mm |
| HF Diaphragm | Carbon dome + PI Surround |
| Crossover | 1.6 kHz 2-way passive network |
| Connectivity |
Genuine NEUTRIK 2pcs Speakon NL4MP |
| Speaker size (HxWxD) | 720 x 410 x 450 mm |
| Speaker Weight | 32 kg |
| Shipping information |
39 kg 820 x 510 x 550 mm |
| Accessories |
PM15-YOKE CPC-70 (pole bar with crank) WMBRKT60 (wall mounting braket) |
